Nissan Leaf Module Details

Module Description:

The Nissan LEAF module contains 4x Lithium NMC pouch cells.  It has a 2s2p configuration, so the middle terminal is to connect between the series cells.

Cell Configuration and Module Types:

Nissan LEAF Types


Voltage and Current Details:

  • Cell Nominal Voltage: 3.65V

  • Cell Voltage Range: 3~4.15V

  • Recommended Voltage cut-off: 4.000V

  • Recommended Voltage cut-off: 3.300V

  • Original Ah Capacity: 66.20Ah

  • Typical Aftermarket SOH: 65%

  • Usable Ah Capacity: 43.03 Ah

 Hardware Details:

  • Main Terminals: M6

    • 5.5±1.0 Nm torque requirements

  • Center Tap: M4

    • 1.2±0.24 Nm torque requirements

Module Dimensions:

  • Length: 11.93in / 303mm

  • Width: 8.78in / 223mm

  • Height: 1.38in / 35mm

  • Weight: 8.38lbs / 3.8kg

Nissan-LEAF-G1-dimensions 2.jpg
